ویسکومتر

توضیحات

 ویسکومتر مدل ROTAVISC LO-VI Complete

Viscosity Measuring Range: 6.000.000 mPas
Viscosity Accuracy (FSR): 1 %
Viscosity Repeatibility (FSR): 0.2 % / Spring torque: 0.0673 mNm
Motor rating output 4.8 W / Speed range: 0.01 – 200 rpm
Setting accuracy speed: ±0.01 rpm
Temperature measurement resolution: 0.1 K
Working temperature -100 – 300 °C
Dimensions (W x H x D) 351 x 629 x 372 mm
Weight 7.1 kg / Permissible ambient temperature 5 – 40 °C
USB interface yes
Permissible relative humidity 80%
Voltage 100 – 240 V / Frequency 50/60 Hz
Power input standby 0.06 W / DC Voltage 24 V=
Current consumption 1000 mA

دانلود کاتالوگ ویسکومتر ROTAVISC LO-VI Complete

ویسکومتر مدل ROTAVISC ME-VI Complete

Viscosity Measuring Range: 40.000.000 mPas
Viscosity Accuracy (FSR): 1%
Viscosity Repeatibility (FSR): 0.2 % / Spring torque: 0.7187 mNm
Motor rating output 4.8 W / Speed range: 0.01 – 200 rpm
Setting accuracy speed: ±0.01 rpm
Temperature measurement resolution: 0.1 K
Working temperature -100 – 300 °C
Dimensions (W x H x D) 351 x 629 x 372 mm
Weight 7.1 kg / Permissible ambient temperature 5 – 40 °C
Permissible relative humidity 80%
USB interface yes
Voltage 100 – 240 V / Frequency 50/60 Hz
Power input standby 0.06 W / DC Voltage 24 V=
Current consumption 1000 mA

دانلود کاتالوگ ویسکومتر ROTAVISC ME-VI Complete

ویسکومتر مدل ROTAVISC HI-VI Complete

Viscosity Measuring Range: 8000000 mPas
Viscosity Accuracy (FSR): 1 %
Viscosity Repeatibility (FSR): 0.2 % / Spring torque: 1.4374 mNm
Motor rating output 4.8 W / Speed range: 0.01 – 200 rpm
Setting accuracy speed: ±0.01 rpm
Temperature measurement resolution: 0.1 K
Working temperature -100 – 300 °C
Dimensions (W x H x D) 351 x 629 x 372 mm
Weight 7.1 kg / Permissible ambient temperature 5 – 40 °C
USB interface yes
%Permissible relative humidity 80
Voltage 100 – 240 V / Frequency 50/60 Hz
Power input standby 0.06 W / DC Voltage 24 V=
Current consumption 1000 mA

دانلود کاتالوگ ویسکومتر ROTAVISC HI-VI Complete
